MB AM4 ASUS TUF GAMING B550M-PLUS

Name: MB AM4 ASUS TUF GAMING B550M-PLUS | HotspotPro
Brand: Matične ploče
SKU: DC30511
Price: 18695.25 RSD
Availability: InStock

Šifra proizvoda: DC30511 Brand: Asus

18.695,25 rsd

Na zalihama

Uporedi

Dodaj na listu želja

Tip procesora:	AMD
Podnožje:	AMD® AM4
Čipset:	AMD® B550
Format ploče:	Micro ATX
Podržana memorija:	DDR4
Podržani procesori:	– Treća generacija AMD Ryzen procesora
Memorija:	3rd Gen AMD Ryzen procesori – 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Next Generation AMD Ryzen PRO Processors – 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory – Dual Channel Memory arhitektura – ECC Memory (ECC mode) podrška varira od verzije CPU-a
Multi-GPU podrška:	– AMD 2-Way CrossFireX tehnologija
Integrisana grafička karta:	– 1 x DisplayPort 1.2 – 1 x HDMI 2.1(4K@60HZ)
Slotovi za proširenje:	3rd Gen AMD Ryzen Processors – 1 x PCIe 4.0 x16 (x16 mode) AMD B550 Chipset – 1 x PCIe 3.0 x16 (x4 mode) – 1 x PCIe 3.0 x1
Skladište:	Ukupna podrška za 2 x M.2 slota i 4 x SATA 6Gb/s porta 3rd Gen AMD Ryzen procesori: – 1 x M.2 Socket 3, sa M Key, Type 2242/2260/2280 (PCIE 4.0 x4 i SATA modes) storage devices podrškom AMD B550 Chipset: – 1 x M.2 soket 3, sa M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 i SATA modes) storage devices podrškom – 4 x SATA 6Gb/s porta, podržava Raid 0, 1, 10
Mrežna karta:	– Realtek RTL8125B 2.5Gb Ethernet – TUF LANGuard
Zvučna karta:	Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC – Podržava: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature: – Exclusive DTS Custom for GAMING Headsets. – Optical S/PDIF out port(s) at back panel – Audio cover – Audio Shielding – Dedicated audio PCB layers – Premium Japanese audio capacitors
USB:	Rear USB Port ( Total 8 ) – 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C) – 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) – 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 6 ) – 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) – 4 x USB 2.0 port(s)(4 x Type-A)
Konektori na zadnjoj strani:	– 1 x PS/2 keyboard/mouse combo port(s) – 1 x DisplayPort – 1 x HDMI – 1 x LAN (2.5G) port(s) – 2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C) – 4 x USB 3.2 Gen 1 (blue) Type-A – 2 x USB 2.0 – 1 x Optical S/PDIF out – 5 x Audio jack(s) – 1 x BIOS FlashBack Button(s)
Interni konektori:	– 1 x CPU Fan connector(s) – 1 x CPU OPT Fan connector(s) – 2 x Chassis Fan connector(s) – 2 x Aura RGB Strip Headers – 1 x Addressable Gen 2 header(s) – 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) – 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) – 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 4.0 x 4 mode) – 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) – 1 x SPI TPM header – 4 x SATA 6Gb/s connector(s) – 1 x 24-pin EATX Power connector(s) – 1 x 8-pin EATX 12V Power connectors – 1 x Front panel audio connector(s) (AAFP) – 1 x Clear CMOS jumper(s) – 1 x System panel connector – 1 x COM port header – 1 x Speaker connector
BIOS:	– 256 Mb Flash ROM, UEFI AMI BIOS
Ostalo:	ASUS TUF PROTECTION – ASUS DIGI+ VRM (Digital power design with Dr. MOS) – ASUS Enhanced DRAM Overcurrent Protection – ASUS ESD Guards – TUF LANGuard – ASUS Overvoltage Protection – ASUS SafeSlot – ASUS Stainless-Steel Back I/O ASUS Q-Design – ASUS Q-DIMM – ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) – ASUS Q-Slot ASUS Thermal Solution – Aluminum M.2 heatsink ASUS EZ DIY – BIOS FlashBack button – BIOS FlashBack LED – Procool AURA Sync – Standard RGB headers – Addressable Gen 2 RGB header
